Electronic Paper Pulp Moulding Machine , Pulp Molding Tableware Equipment
Paper Pulp Moulding Machine Description:
- Take clean virgin paper as raw material, such bagasse pulp, bamboo pulp, straw pulp, reed pulp and etc.
- The forming machine complete the forming, drying and hot-press shaping procedures, but needs labor transfer.
- Application: Compostable tableware, food trays, cup holder, simple industrial package, etc.
- The products made by our machines are food grade and environmental friendly.
Paper Pulp Moulding Machine Specifications:
| Automation | Model | Mould Size | Pressure | Capacity / Set | Robot Match |
| Semi Automatic | BY010 | 900*600mm | 20ton | 15~20kg/h | Manual operation / Match Robot |
| BY040 | 1100*800mm | 40ton | 30~35kg/h | Manual operation / Match Robot |
| BY050 | 1000*950mm | 40ton | 30~35kg/h | Match Robot |
| The capacity will depend on the quantity of forming machines. |
Paper Pulp Moulding Machine Main Features:
| Heating Way | Electricity or thermo conduction oil |
| Forming Type | Vacuum suction, thermoforming |
| Drying Method | Drying in mould |
| Water Proof | Add water proof chemical (AKD) ; food grade |
| Oil Proof | Add oil proof chemical ; food grade |
| Semi Automatic | Flexible for various products but small capacity |
Paper Pulp Moulding Machine Picture:
How the Production Line Works:
Pulping System: Turn clean virgin paper into pulp of certain consistency. Main equipment: hydrapulper, pulp tanks, water tank, pulp pump, water pump, agitator, etc.
Forming and Drying System: When adjusting the pulp consistency, the pulp will go to the forming machine. Products will be formed on the moulds. Then needs labor to transfer products on heating hot press moulds.
Vacuum System: Supply vacuum for forming machine.
Air Compressor System: Supply compressed air for forming machine.
Cutting System(Edge Trimming Machine): Cutting the extra edges of products, to get more compact and neat edge.
Disinfect System: UV or microwave disfect, then go to package.
YOUTUBE Links:
| Semi Automatic Tableware Production Line | http://Paper Pulp Moulding Machine |
| For more videos, you can search "Guangzhou Nanya Pulp Molding Equipment Company" on YOUTUBE and subscribe us. |
Applications:
- Compostable tableware, food trays, cup holder, simple industrial package, etc.
- For jewelre box, phone box, wine box, tea box, makeup box;
- For high-grade electronics products, tools, hardware etc and etc
The below are products made by our machines, by changing moulds, the machine can make different products.
Why NANYA is Your Best Choice?
Rich Experience: Established in 1994, With 30 years of experience, we will make quotation and analysis based on customer’s investment and capacity.
Technology Guarantee: Combined with high and new technology with government institution and South China University of Technology, with over 30 R&D personnel;
Quality Guarantee: Life-long service, sustainable supply and upgrade of parts and components, One-year warranty( three-year warranty for mechanical parts and main machine)
Wide Market: NANYA has more than 60% of the domestic demands, already exported to over 80 countries and regions;
Strong Teams: Excellent engineers, sales and after sales service team brings the best service to ensure long-term satisfaction for our customers.
Business Terms:
| Delivery Terms | FOB Guangzhou or Shenzhen, China. (CNF and CIF are also available.) |
| Delivery Time | 45~75 days |
| Package | Export Standard Packing |
| Warranty | 12 months |
| Installation | We will appoint 1 or 2 engineers to instruct buyer in installation, test-run and training. |
| Quotation Validity | 90 days after the offering date |
| Aftersales Service | We will send some spare parts by free. And we will provide operating manual, drawing, process diagram for all of the machine. We will instruct the operation, maintain method for the buyer’s worker after installation. |
